Electrolysis Condenser 0.05mm Min Thickness Tantalum Foil

Product Categories

Zhengzhou Sanhui Refractory Metal Co., Ltd.

Contact Now

Electrolysis Condenser 0.05mm Min Thickness Tantalum Foil

Model Number : Customized

Place of Origin : China

MOQ : 1 Kilograms

Payment Terms : T/T

Supply Ability : 50 Kilograms per Month

Delivery Time : 20 days after order

Packaging Details : Exported plywood case with foam inside

Product Name : Tantalum Foil

Thickness : 0.05mm min

Width : 30mm-150mm

Purity : 99.95min

Density : 16.5 g/cm3

Conditions : Annealed

Contact Now

Pure 99.95% ASTM B708 Tantalum Foil for Electrolysis Condenser

Product Description:

1. Product name Tantalum Foil

2. Purity 99.9~99.99%

3. Standard ASTM B708

4. Thickness 0.05mm - 0.1mm

5. Application Used for numerous heating element application

6. Strict quality control System: Each link of the production will be strickly controled,ensuring without one un-qualified product being out from our company.

7. Certification Report: Material Certification,CE,SGS, or testing report will be offered.

8. Chemical Compositions of tantalum foil

Chemistry ppm
Designation	Chief component		Impurities maxmium
Designation	Ta	Nb	Fe	Si	Ni	W	Mo	Ti	O	C	H	N
Ta1	Remainder	300	40	30	20	40	40	20	150	40	15	20
Ta2	Remainder	800	100	100	50	200	200	50	200	100	15	100
TaNb3	Remainder	<35000	100	100	50	200	200	50	200	100	15	100
TaNb20	Remainder	170000- 230000	100	100	50	200	200	50	200	100	15	100
Ta2.5W	Remainder	400	50	30	20	30000	60	20	150	50	15	60
Ta10W	Remainder	400	50	30	20	110000	60	20	150	50	15	60

9. Specification of tantalum foil

	Thickness (mm)	Width (mm)	Length (mm)
Foil	0.05~0.1	30~150	>=200
Sheet	0.1~0.5	30~500	>=200
Plate	0.5~25	50~500	>=200

Product Tags:

astm b708 ta foil

annealed tantalum products

0.05mm min thickness ta foil
